Comparatif des SMART Board pour l'enseignement
Télécharger une version PDF imprimable de ce tableau
Les modèles et les spécifications peuvent varier selon les régions. Veuillez contacter votre représentant local pour obtenir plus de détails.
 |
 |
 |
|---|
| Software | GX (V3) series | MX (V5) series | RX series |
|---|---|---|---|
| SMART Notebook® | Included | Included | Included |
| SMART Notebook Plus | Optional | Optional | Optional |
| Lumio™ | Optional | Optional | Optional |
| SMART Product Drivers and SMART Ink® | Included | Included | Included |
| SMART Remote Management | Optional | Subscription for the length of the warranty | Subscription for the length of the warranty |
| Embedded features |
Digital whiteboard Web browser Screen sharing Input select File manager Overlay Split screen Picture-in-picture (PIP) with touch pass-through Interactive widgets App library |
Digital whiteboard Chrome™ browser Screen sharing Google Play™ store Personalized home screen and settings Input select Split screen PIP with touch pass-through Interactive widgets Templates, graphic organizers, and manipulatives File and app libraries Google Drive™ and OneDrive™ access |
Digital whiteboard Chrome browser Screen sharing Google Play store Personalized home screen and settings Input select Split screen PIP with touch pass-through Interactive widgets Templates, graphic organizers, and manipulatives File and app libraries Environmental sensors dashboard Tool Explorer™ Image Editor Google Drive and OneDrive access |
| Display | GX (V3) series | MX (V5) series | RX series |
| Screen sizes (diagonal) | 65" | 75" | 86" | 55" | 65" | 75" | 86" | 65" | 75" | 86" |
| Resolution | 4K UHD (3840 × 2160) | 4K UHD (3840 × 2160) | 4K UHD (3840 × 2160) |
| Refresh rate | 60 Hz | 60 Hz | 60 Hz |
| Lifespan | ≥ 50,000 hours | ≥ 50,000 hours | ≥ 50,000 hours |
| LCD quality | Grade A | Grade A | Grade A |
| Brightness1 | 400 cd/m² |
55": 300 cd/m² 65", 75", 86": 400 cd/m² |
490 cd/m² |
| Display response time | ≤ 8 ms | ≤ 8 ms | ≤ 8 ms |
| Glass | Full heat-tempered | Anti-glare | Bonded | 55": Full heat-tempered | Anti-glare 65", 75", 86": Full heat-tempered | Anti-glare | Bonded | Optically bonded | Anti-glare | Anti-fingerprint | Heat-tempered |
| Sensors | Ambient light | Infrared | Proximity2 | Ambient light | Infrared | Proximity | Ambient light | Infrared | Room temperature | Humidity | Equivalent carbon dioxide (eCO2) | Volatile organic compound (VOC) | Particulate Matter (PM2.5) |
| Speakers | 2 integrated 20 W speakers |
55": 2 integrated 15 W speakers 65", 75", 86": 2 integrated 20 W speakers |
Integrated soundbar featuring two 20 W speakers and a 15 W subwoofer |
| Microphone | N/A | Integrated linear six-microphone array with support for onboard acoustic echo cancellation | Integrated linear eight-microphone array with visual mute status indicator and support for onboard acoustic echo cancellation |
| QR code sign in to a SMART Account | |||
| NFC sign in to a SMART Account | |||
| Convenience buttons | Power | Home | Volume | Freeze frame | Power | Home | Volume | Input select | Screen shade | Freeze frame | Power | Home | Volume | Microphone mute | Freeze frame |
|
1Brightness of individual displays can vary. 2Only available on some models |
|||
| Touch and interaction | GX (V3) series | MX (V5) series | RX series |
| Touch technology | Advanced infrared | HyPr Touch™ with Advanced IR | HyPr Touch with Advanced IR |
| Frame rate | ≥ 125 Hz | ≥ 200 Hz | ≥ 300 Hz |
| Touch response time | ≤ 8 ms | ≤ 5 ms | ≤ 4 ms |
| Accuracy | 1 mm | 1 mm | 1 mm |
| Minimum object size | 2 mm | 2 mm | 2 mm |
| Continuous touch points (fully differentiated) | Up to 40 touch points (OS dependent) | Up to 50 touch points (OS dependent) | Up to 50 touch points (OS dependent) |
| Interaction types | Pens | Touch | Gesture | Palm erase | Pens | Touch | Gesture | Palm erase | Pens | Touch | Gesture | Palm erase | Erase | Fine erase | Tool Explorer tools |
| Eraser, pen, and touch differentiation (simultaneous tool differentiation) | 3 | ||
| Continuous pen, touch, and erase (continuously write, move, and gesture and erase simultaneously) | 3 | ||
| Eraser types | Palm erase | Palm erase | Palm erase | Fine erase | Eraser blocks |
| Azimuth erasing | N/A | N/A | Eraser blocks |
| Palm rejection | Non-writing hand in Android™ whiteboard | N/A | Writing and non-writing hand |
| Object recognition | 4 | ||
| Pressure-sensitive ink | |||
| Automatic pen color recognition | |||
| Unique Pen ID support | 2: Windows® and macOS, when using a finger to write or draw | 2: Windows and macOS, when using a finger to write or draw | Unlimited |
| Tools included | Pens (×2) | Pens (×2) |
Stylus with multi-color select and fine eraser (×2) Erasers with angle of orientation (×2) |
| Tool holders | Magnetic | Frame‑mounted | Magnetic | Frame‑mounted | Intelligent | Magnetic | Frame‑mounted |
|
3A connected computer with SMART Product Drivers installed is required. Only supported in SMART Notebook and SMART Ink. 4When connected to a computer with SMART Product Drivers installed |
|||
| Embedded Android OS | GX (V3) series | MX (V5) series | RX series |
| Operating system | Android version 13.05 |
Android version 13.0 (Automatic update to Android version 15.0 scheduled for the second half of 2025.) |
Android version 13.0 (Automatic update to Android version 15.0 scheduled for the second half of 2025.) |
| CPU | Quad-core | Octa-core | Octa-core |
| Memory | 8 GB DDR4 | 8 GB DDR4 | 8 GB DDR4 |
| OS architecture | 64-bit | 64-bit | 64-bit |
| Storage | 64 GB | 64 GB (up to 576 GB) | 64 GB (up to 576 GB) |
| User interface | 4K UHD (3840 × 2160) | 4K UHD (3840 × 2160) | 4K UHD (3840 × 2160) |
| Updates | Over‑the‑air (OTA) | Automatic OTA | Automatic OTA |
| 5Previous displays that included Android 11 are upgradeable to Android 13. | |||
| Network connectivity | GX (V3) series | MX (V5) series | RX series |
| Wired | RJ45 (×2) 1000BASE-T | RJ45 (×2) 1000BASE-T | RJ45 (×2) 1000BASE-T |
| Wi-Fi |
IEEE 802.11ax (Wi-Fi 6) supporting WEP, WPA, WPA2, WPA3 PSK, and 802.1X EAP authentication protocols Wi-Fi hotspot |
IEEE 802.11ax (Wi-Fi 6e) supporting WPA, WPA2, WPA3 PSK, and 802.1X EAP authentication protocols Wi-Fi hotspot |
IEEE 802.11ax (Wi-Fi 6e) supporting WPA, WPA2, WPA3 PSK, and 802.1X EAP authentication protocols Wi-Fi hotspot |
| Bluetooth® | 5.0 dual mode | 5.2 dual mode | 5.2 dual mode |
| Classroom connectivity | GX (V3) series | MX (V5) series | RX series |
| Number of student devices connected to the display | 9 | 40+ through any web browser, no sign in required6 | 40+ through any web browser, no sign in required6 |
| Whiteboard broadcast | N/A |
200 (unlimited)6 Live content and annotation updates |
200 (unlimited)6 Live content and annotation updates |
| Student device collaboration activities | |||
| Whole-class collaboration tools | N/A |
Two-way annotation: ink and text tool to whiteboard canvas with student attribution Polling and voting Checks for understanding Questioning and reflection exercises Freeform or categorized brainstorming and ideation Activating prior knowledge exercises |
Two-way annotation: ink and text tool to whiteboard canvas with student attribution Polling and voting Checks for understanding Questioning and reflection exercises Freeform or categorized brainstorming and ideation Activating prior knowledge exercises |
| Device connection options (screen share) |
|
|
|
| Device connection options (whiteboard) | N/A |
Live whiteboard broadcast through any web browser Contribution access through any web browser, including collaboration activities |
Live whiteboard broadcast through any web browser Contribution access through any web browser, including collaboration activities |
| Teacher control options (screen share) | Moderated with 9× grid view |
Unmoderated Moderated with 4× grid view |
Unmoderated Moderated with 4× grid view |
| Teacher control options (whiteboard) | N/A |
Teacher-led navigation Student-paced navigation Pause contributions to collaborative whiteboard canvas |
Teacher-led navigation Student-paced navigation Pause contributions to collaborative whiteboard canvas |
| 6Unlimited connections available to whiteboard. Speed and function subject to individual network capabilities. | |||
| Inputs | GX (V3) series | MX (V5) series | RX series |
| OPS PC accessory slot | |||
| microSD slot | |||
| HDMI® |
(×3) HDMI 2.0 with HDCP 1.4 and HDCP 2.2 support |
(×4) HDMI 2.1 4K @ 60Hz with HDCP 1.4, HDCP 2.3, ARC, and eARC support (ARC and eARC support are available only with the HDMI 2 input.) |
(×4) HDMI 2.1 4K @ 60Hz with HDCP 1.4, HDCP 2.3, ARC, and eARC support (ARC and eARC support are available only with the HDMI 2 input.) |
| Display Port 1.2 | |||
| VGA video | |||
| Stereo 3.5 mm (variable) | |||
| RS-232 (DB-9 connector) | |||
| RJ45 (LAN IN) | |||
| USB Type‑C |
(×2) Front: 15 W power delivery |
(×2) Front: 27 W power delivery; Side: 65 W power delivery |
(×2) Front and side: 65 W power delivery; Top: 15 W power delivery |
| USB 2.0 Type-A | |||
| USB 3.2 Gen 1 Type‑A | (×4) | (×4) | (×4) |
| USB 2.0 Type-B | (×2) | ||
| USB 3.2 Gen 1 Type‑B | (×4) | (×4) | |
| Outputs | GX (V3) series | MX (V5) series | RX series |
| HDMI |
HDMI 2.0 with HDCP 1.4 and 2.2 support |
HDMI 2.1 4K @ 60Hz with HDCP 2.3 support |
HDMI 2.1 4K @ 60Hz with HDCP 2.3 support |
| USB Type‑C |
4.5 W power delivery |
4.5 W power delivery |
|
| Stereo 3.5 mm (variable) | |||
| S/PDIF optical (fixed) | |||
| RJ45 (LAN OUT) | |||
| OPS accessory slot | GX (V3) series | MX (V5) series | RX series |
| OPS support | SMART PCM or AMG1 | SMART PCM | SMART PCM |
| OPS power delivery | 90 W | 85 W | 100 W |
| Installation | GX (V3) series | MX (V5) series | RX series |
| VESA mounting points | |||
| Wall mount bracket | Optional | Optional | Optional |
| Included cables and accessories |
Pens (×2) Remote control Country-specific power cable USB Type-A to Type-B cable |
Pens (×2) Remote control Country-specific power cable USB Type-A to Type-B cable USB Type-C cable |
Stylus with multi-tool select and fine eraser (×2) Erasers (×2) Remote control Country-specific power cable USB Type-A to Type-B cable USB Type-C cable |
| Certification and compliance | GX (V3) series | MX (V5) series | RX series |
| US / Canada | cULus | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 | UL | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 |
| EU / EEA / EFTA / UK | CE | UKCA | LVD | CB | EMCD | RED | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign | CE | UKCA | LVD | CB | EMCD | RED | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign | CE | UKCA | LVD | CB | EMCD | RED | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign |
| Australia / New Zealand | RCM | RCM | RCM |
| Performance standards | ENERGY STAR® | HDMI | HDCP | ENERGY STAR | HDMI | HDCP | ENERGY STAR | HDMI | HDCP |
| Warranty | GX (V3) series | MX (V5) series | RX series |
| SMART Warranty | Included. See warranty page for details. | Included. See warranty page for details. | Included. See warranty page for details. |
